Enhanced TL-D3 PRO V2 Dual Extruder 3D Printer (Refurbished)
  • $439.99

  • $549.99
  • Product Code: 01-TLD3-V2-R
  • Availability: Out Of Stock
- +

Our TL-D3 Pro Dual Extruder 3D Printer has double nozzles that are independent of each other, allowing you to print in dual materials/ duplication/mirror mode. The TL-D3 Pro gives you better creative tools and twice the productivity!

1. Dual Material PrintingYou can use two colored filaments to print on the model to obtain two-color models, or use two different filaments to print soluble supports (such as PVA) to accurately achieve difficult-to-place models.

2. Duplication Mode PrintingYou can print two identical models of filaments (or the same or different filaments) of the same color or different colors on the Tenlog 3D printer at the same time, thereby doubling the printing efficiency and saving you time!

3. Mirror Mode PrintingYou can print two symmetrical models of filaments (or the same or different filaments) of the same color or different colors on the Tenlog 3D printer at the same time,the two nozzles are dual-driven at all times for printing, and the two models are immediately aligned with the mirror.

4.Resume Printing FunctionIn the event of an unexpected power outage or surge, the control board will remember the last recorded position of the extruder. After the power is restored, The 3D printer will resume printing from the last recorded position.

5.Filament Runout Detection : When the filament runout detection detects that the filament such as PLA or ABS are used up or broken, the 3D printer will save the information and suspend printing, waiting for the 3D printer to feed the filament again to continue printing.

GENERAL
Motor Controller/Driver TMC2209
Machine Size (WxDxH) 23.2 x 20.5 x 29.9 inch / 590 x 520 x 760 mm
Nozzle Quantity 2
Nozzle Diameter 0.4mm
XY-Axis Positioning Accuracy 11 um
Z-Axis Positioning Accuracy 2.5 um
Additive Manufacturing Accuracy ±0.1mm
Layer Thickness 0.1mm-0.4mm
Nozzle Temperature Max 300 ℃
Heatbed Temperature MAX 110℃
Printing Speed 10-150 mm/s
Supported Filaments TPU, PVA, PLA, ABS, HIPS, WOOD, PETG, FLEXIBLE
Screen 4.3-inch 480*272 Resolution Full Color Capacitive Touch Screen
Frame Material Aluminum Alloy & Sheet Metal
Platform Board Aluminum Alloy & Glass
Language English, Language custom accepted
Machine Weight 15.6Kg
Shipping Box Size 26 x 23.6 x 10.2 inch / 660 x 600 x 260 mm
Volumetric(Dimensional) Weight 21Kg
ELECTRICAL
Filament Detection Yes
Input Power 100-240 V AC 50/60 Hz
Build Volume (WxDxH) 11.8 x 11.8 x 13.8 inch / 300 x 300 x 350 mm
Output Power 24 V, Max 25A
Filaments Diameter 1.75mm
Voltage Range 110-120V / 6.8A, 200 - 240V / 3.4A, 50 / 60Hz
SOFTWARE
File Preparation Software Cura, Repetier-Host
Support File Type G-code, STL, jpg, etc.
Supported Operating System XP, WIN7/8/10, Linux
